ECD S80 Intelligent pH Monitor

SKU: S80-0-pH
Intelligent pH Monitor
Stores identity and calibration information
Replaceable electrode cartridges
Application Specific electrodes available
Insertion and submersion options

  • Sensor Style
  • Housing Material / Length
  • Fitting
  • Cable Length
  • T Handle
  • Electrode Type
  • Transmitter
  • Power Supply
  • Outputs
  • Mounting Hardware
  • £1195.00
  • £1434.00 inc VAT
Qty:

Description

  • Weight
    275.0000 kg
  • SKU
    S80-0-pH
S80 Intelligent pH Monitor

Intelligent pH Monitor
Stores identity and calibration information
Replaceable electrode cartridges
Application Specific electrodes available
Insertion and submersion options


The S80 pH sensor is one of the key Monitors on offer from the ECD S80 sensor range. The Sensor works by converting the analog signals from the electrode sensor cartridge into a digital protocol which allows for two way communications with the transmitter. The identity of sensor, type and serial number, are stored in the sensor’s internal memory along with the units three calibration registers. When connected to an ECD T80 the sensor’s information is uploaded to the analyser. This automatically configures the display and outputs of the transmitter to the values appropriate to the measurement range and type.

Key Features of the S80 include -

  • Intelligent sensor design - storage of calibration and identity information
  • Multiple measurement options - pH, ORP, Specific Ion, Dissolved Oxygen and more
  • Application specific electrodes - pH electrode designed for specific applications
  • Field replaceable electrode cartridges
  • Submersible and retractable mounting options
  • Industrial housing materials for process applications
